Wastewater Treatment Plant

Wastewater Treatment Plant

Fairfield, IA

In response to a 2008 Administrative Consent Order aimed at eliminating sanitary sewer overflows (SSOs), the City submitted an I/I Reduction Plan prepared by a local firm. The plan identified 21 collection system projects totaling $21.6 million to be completed by 2019. However, the political challenges associated with implementing a broad home inspection and footing drain disconnection program prompted the City to reconsider its strategy. At the same time, the City faced major deficiencies at its Wastewater Treatment Plant (WWTP), including a non-functioning preliminary treatment system that negatively impacted downstream processes. Compounding the issue was the lack of reliable influent flow data during storm events, caused by years of deferred maintenance and nonfunctioning equipment. These factors led to highly variable effluent discharge volumes and inconsistent treatment performance.
To address these concerns, McClure partnered with the City and the Iowa Department of Natural Resources (DNR) to develop a comprehensive, data-driven strategy. The team focused on quantifying actual flow patterns entering the collection system and WWTP during storm events—critical for long-term planning and infrastructure design. This effort resulted in the Sanitary System Evaluation Survey and the establishment of an eight-year Sanitary Transportation and Elimination Program (STEP).
The STEP program introduced a phased, holistic approach aimed at reducing and ultimately eliminating SSOs, minimizing the risk of basement sewage backups, rehabilitating the aging collection system, and implementing substantial improvements at the WWTP. This strategy enabled the City to shift away from politically challenging residential programs and instead focus on measurable system-wide improvements to achieve regulatory compliance and enhance long-term operational resilience.

Highlights

  • Constructed influent and stormwater pump structure featuring parallel, two-stage 9 MGD Archimedes screw pumps and four 11 MGD submersible stormwater pumps
  • Developed a 20 MG flow equalization basin equipped with flow metering and control structures
  • Designed a new headworks building with mechanical screening and vortex grit removal systems
  • Added a third oxidation ditch with jet aeration mixing, a 70-foot diameter internal clarifier, and return activated sludge (RAS) pumping
  • Upgraded two existing oxidation ditches and final clarifiers with new jet aeration mixing systems
  • Implemented UV disinfection and plant water systems, including vertical UV lamps, non-potable water pumping, and a seasonal bypass
  • Constructed a second 90-foot diameter aerobic digester with a jet aeration system and dedicated blower building
  • Completed all supporting upgrades to electrical systems, HVAC, controls, and SCADA infrastructure

Discipline

Water

Project Type

Wastewater Treatment Plant

Client

City of Fairfield, IA
