AIRPORT MASTER PLAN UPDATE

Project Overview

McClure provided surveys, permits, railroad coordination, preliminary and final bridge design, and construction observation services to replace Bridge No. 3670020 utilizing the BRO program. The existing structure was a wooden bridge over the Kansans City Southern Railroad Randolph County, Missouri, and had been repaired due to collision damage and structural deficiencies. The final design included a single span structure with Geosynthetic Reinforced Soil (GRS) abutments for the substructure and precast concrete box beams for the superstructure with a concrete deck. A concrete crash wall was also included in front of each abutment. This innovative bridge design, known as GRS-IBS, stands for Geosynthetic Reinforced Soil – Integrated Bridge System, which was the second one completed in the state of Missouri and the first one over a railroad. Additional width provided by the new structure allowed for two-way traffic and large agricultural equipment.



Project Highlights:

  • Second Geosynthetic Reinforced Soil-Integrated Bridge System constructed in Missouri.
  • Design involving aggregate and fabric faced with block wall.
  • Concrete box girders.
  • Innovative approach saving time and money by simplifying construction process.

Location:

Mount Pleasant, Iowa

Services:

Master Planning

Airport Layout Plans

Airport GIS System

Capital Improvement Planning



Location:

Mount Pleasant, Iowa

Services:

Master Planning

Airport Layout Plans

Airport GIS System

Capital Improvement Planning
